1、 Equipment Overview
A safety valve is a device used to control pressure and is widely used in equipment such as pipelines and pressure vessels. The safety valve will inevitably experience wear or failure during long-term use, and it is necessary to use a safety valve grinding table for maintenance and repair.
The safety valve grinding table adopts a dynamic grinding method to repair the sealing surface of the safety valve seat. Its working method is to rotate the safety valve seat, hold the grinding tool stationary, and keep the plane in contact with the sealing surface of the valve seat, so that the sealing surface is evenly ground. Practice has proven that the effect is good. The valve needs to move multiple trajectories during grinding in order to achieve uniform grinding of the sealing surface and achieve satisfactory flatness requirements. The refrigeration of sealing surface grinding depends on the flatness and hardness of the grinding tool and the operating method.
2、 Equipment structure
The safety valve dynamic grinding machine consists of a single-phase AC motor, a reducer, a frequency converter, a workbench, and accessories.
This equipment is a dual station, with the right station used for grinding the valve seat sealing surface and the other station for grinding the valve disc sealing surface.
Considering the different diameters of the safety valve, there is a frequency conversion speed control device and a porous plate configuration to adapt to the changing linear speed.
Safety valve grinding table
3、 Characteristics of safety valve grinding table
1. Dynamic grinding of valve seat: The valve body rotates and is ground with a handheld grinding tool, which can maintain gentleness and retain the advantages of manual grinding, overcoming the shortcomings of low efficiency in manual grinding.
2. Multi trajectory grinding of valve discs.
3. Dual station: capable of grinding both the valve seat and disc simultaneously.
4. Efficient and high-quality: Easy to clamp and change specifications, low labor intensity, and no need for professional training.
5. Widely used: various specifications of positioning heads and porous plate configurations, suitable for grinding various diameters, various safety valves, and other flat metal surfaces within the specifications.
6. Adjustable automatic grinding agent (oil) device.
7. Unidirectional 220V civilian electric drive.
4、 Technical parameters of safety valve grinding table
Power supply: AC 220V 4A
Structure: Variable frequency speed regulation
Speed: 0-30 rpm
Grinding diameter: 32-150mm
Valve seat station: 1
Disc workstation: 1
Floor area: 1.5 meters x 0.75 meters
Equipment self weight: approximately 400KG
Technical specifications and parameters in accordance with GB1047-2005
